Projektor NEC NP3250W

Display

3 x 1.879 cm (0.74") p-Si LCD Panel with MLA (Aspect Ratio 16:10)

Native Resolution

1280 x 800 (WXGA)

Brightness ¹

4000 ANSI Lumens (approx. 80% in Eco Mode)

Contrast Ratio ¹

500:1

Lamp

330 W (264 W Eco Mode)

Lamp Life [hrs]

2000 (3000 Eco Mode)

Lens

F= 1.7–2.2, f= 24.4–32.5 mm

Projection Factor

1.5 – 2 : 1

Projection Distance [m]

0.89 – 20.8

Wielkość (przekątna) ekranu [cm]

Minimalnie: 76 / 30" ; Maksymalnie: 1 270 / 500"

Zoom

Manual

Focus Adjustment

Manual

Supported Resolutions

1920 x 1080 (HDTV 1080i @50/60Hz) with Advanced AccuBlend™ Technology; 1600 x 1200 (UXGA); 1400 x 1050 (SXGA+); 1280 x 1024 (SXGA); 1280 x 800 (WXGA); 1280 x 720 (HDTV 720p); 1152 x 900 (SGI, SUN); 1152 x 870 (Mac); 1024 x 768 (XGA); 832 x 624 (Mac); 800 x 600 (SVGA); 768 x 576 (PAL 15.6 kHz); 720 x 557 (SDTV 557p); 720 x 480 (SDTV 480p); 640 x 480 (VGA/Mac); 640 x 480 (NTSC 15.7 kHz)

Frequency

Horizontal: 15–108 kHz (RGB: 24 kHz or more); Vertical: 48 – 120 Hz

RGB (analog)

Input: 1 x Mini D-sub 15-pin, compatible to component (YPbPr); 1 x 5BNC, shared with Component Signal (YPbPr)
Output: 1 x Mini D-sub 15 pin

Video

Input: 1 x RCA

S-Video

Input: 1 x Mini DIN 4-pin

Audio

Input: 2 x 3.5 mm Stereo Mini Jack for Computer analog and digital; 1 x RCA Stereo for Video, S-Video and Component
Output: 1 x 3.5 mm Stereo Mini Jack (variable) for Computer 1, 2, 3 (DVI-D), Component, Video and S-Video

PC Control

Input: 1 x D-Sub 9 pin (RS-232) (male)

LAN

1 x RJ45, 10/100 base-T and W-LAN by Wireless LAN Module (removable)

USB

1 x Type A (USB 2.0 high speed)

Video Signals

PAL; PAL60; NTSC; SECAM; NTSC 4.43; PAL-N; PAL-M

Computer Digital

Input: 1 x DVI-D (with HDCP)

Component

Input: 1 x 3 RCA

Input:

1 x 3.5 mm Stereo Mini Jack

Remote Control

Type RD-433E; 3D Reform™ Control; Aspect Ratio; Automatic Picture Adjustment; Freeze-function; Help-function; IR and LAN Control; Lamp Mode Control; Laser Pointer; Magnify-function; PC Mouse Control; Page Control; Picture Mute; Source Select

Power Supply

100-120 V/200-240 V AC; 50 - 60 Hz

Power Consumption [W]

490 Normal Mode; 410 Eco Mode

Dimensions (W x H x D) [mm]

399 x 150 x 358 (without lens and feet)

Weight [kg]

7.5

Fan Noise [dB (A)]

38; < 30 Eco Mode

Optional Accessories

Ceiling Mount Kit (NP30UCM); Hardcase (NP01TC); Lamp (NP06LP); YUV Cable (ADP-CV1)
Lenses: NP01FL (0.8:1); NP02ZL (1.2-1.5:1); NP03ZL (1.9-3.1:1); NP04ZL (3-4.8:1); NP05ZL (4.7-7.2:1)

Safety and Ergonomics

CE; EuP; TÜV GS; RoHS

Speakers [W]

2 x 5 (stereo)

Projektory

3 years pan-European service

Lamp

6 months, max. 1000 hrs
